P1.2 | P1.5 | P1.9 | P2.5 | |
Pixel Pitch (mm) | 1.2 | 1.5 | 1.9 | 2.5 |
LED configuration | 1Red, 1Green, 1Blue | |||
LED Type | 3 in 1 SMD | |||
Module Size (mm) | 152.48 x 171.54 | |||
Cabinet Material | Aluminum Die-Casting | |||
Cabinet Size (mm) | 609.92 x 343.08 x 68 | |||
Pixel Matrix Per Cabinet (Dots) | 480 x 270 | 384 x 216 | 320 x 180 | 240 x 135 |
Weight Per Cabinet (kg) | 7 | |||
Refresh Rate (Hz) | 1920-3840 | |||
Driving Type | 1/16 scan | – | – | – |
Brightness (nits) | 600 | 600 | 800 | 800 |
Max Power (W/Cabinet) | 140 | 140 | 120 | 120 |
Avg Power (W/Cabinet) | 46 | 46 | 40 | 40 |
Life Span | 100,000+ Hours | |||
Installation Maintenance | Full front service | |||
Ingress Protection | IP60 | |||
Operating Temperature/Humidity | -10℃~+45℃ / 10~80% RH | |||
Storage Temperature/Humidity | -20℃~+55℃ / 10~85% RH | |||
Certification | CE/CB/ROHS/CCC |
